THE

BRILLIANT

ADVENT FS 9

This AAOM Brilliant Advent FS-9 Ophthalmic surgical microscope is designed to provide high contrast and detailed imaging of all regions of the human eye. Its optics offers a higher quality view with improved efficiency to doctor's working conditions

Precise Optics

The AAOM Brilliant Advent FS-9 has a converging binocular optical head with Precise Optics. The major advantage of this microscope is that it allows deep light penetration, provides greater visibility and better Surgical perception. Its optics offers a higher quality view with improved efficiency to doctor's working conditions.

Ideal Light Source

The LED illumination emits a light beam that penetrates even in the most inaccessible areas during the surgical procedures, thus illuminating your field of view with uniformity

Enhanced Magnification

The AAOM Brilliant Advent FS-9 provides five-steps zoom magnification varying from 0.4x, 0.6x, 1.0x, 1.6x, 2.4x. To improve surgeon convenience the control knobs are located on the sides of the microscope head for selecting the desired magnification. Manual magnification changer is provided with an additional option of motorized magnification. Sterilizable protectors are attached on the magnification changer knobs and the microscope positioning handle

Tiltable Eye Piece (Binocular)

When work surfaces are set at elbow height to facilitate hand operations, the Tiltable eyepiece allows the Doctor to set the microscope's eyepiece height to achieve a good ergonomic neutral posture. Adjustability eliminates raised shoulders and bent necks, which can cause discomfort.

X-Y Coupling Unit

The ± 65mm stroke both in X and Y directions allow the surgeon to cover an extensive area during the cataract Surgery. With the introduction of an upgraded X-Y Coupling, reliability in positioning has been improved.

Brilliant advent microscopeBrilliant Advent designBrilliant Advent designBrilliant Advent designBrilliant Advent designBrilliant Advent design

Ergonomic Design

Perfect ergonomic facilitating the diagnostic examination saving more working space and creating more access to surgical areas and distracting features were deliberately omitted.Crafted by enhancing the unit, compatible with several other features:

assistant microscope image

Build-In Hd Camera

It has an UHD digital camera integrated with seamless designed microscope capable of Streaming high resolution video.

assistant microscope image

Assistant Microscope

ret view image

Ret View

re inverter image

Re inverter

beam splitter image

Beam Splitter

c mount image

C-Mount

ccd camera image

CCD Camera

foot switch image

Foot Switch

Foot controller is the default selection where the zoom function of the microscope and the X-Y coupling are selected. The foot controller allows 8-way operations: main lamp on/off, X direction movement Left, X direction movement Right, Y direction movement Up, Y direction movement Down, focusing up, focusing down, zoom up and zoom down, & Reset.

Technical Specifications

Surgical Microscope

Vertical Storke

600mm

Eyepiece

10x (Option 12.5x )

Optics

Apochromatic

Binocular tube

45° inclined / 90° Tillable, F=200mm

Magnification changer

Manual step (Option Motorized step zoom 1: 6) Foot Control

Magnification

0.4x, 0.6x, 1.0x, 1.6x, 2.5x

Objective

F=225mm (Option F=200mm)

Focusing

Motorized Focusing with Foot Control

Electrical Specifications

Power supply

~110-230 V,50-60Hz

Power in VA

50 VA

Light source

LED

Fuse rating

2A

Classification

Class 1 type B

Illumination

  • Bright LED, day light adjustable and integrated 00 co-axial red glow illumination system

  • Yellow, retinal guard and integrated heat filter

  • XY Coupling with Foot Control

  • Adjustment range - 60 mm x 60 mm

  • Push button for initial position of X-Y

Standard Accessories

  • In-Built Camera with Display System • Sterilizable caps(2 sets), • Dust cover(1)

Optional Accessories

  • Sterilizable components for all drive knobs

  • Eye pieces 12.5x

  • Beam Splitter, C-Mount, CCD Camera

  • Assistance Scope

  • RET VIEW with Re-Inverter

***Designs and details are subject to change without prior notice for the purpose of product development***
